SAMSUNG Digital Signage 98" UHD/4K 16:9 QM98C LH98QMCEBGCXEN
Specifications
| Display |
| Display diagonal | 2.49 m (98") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Panel type | VA |
| Native aspect ratio | 16 |
| Response time | 8 ms |
| Contrast ratio (typical) | 5500 |
| Dynamic contrast ratio marketing name | Mega Contrast |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.562 x 0.562 mm |
| Colour saturation | 25% |
| Horizontal scan range | 30 - 81 kHz |
| Vertical scan range | 48 - 75 Hz |
| Ports & interfaces |
| HDMI ports quantity | 3 |
| DisplayPorts quantity | 1 |
| USB port | Yes |
| HDMI version | 2.0 |
| DisplayPorts in | 1 |
| DisplayPort version | 1.2 |
| USB ports quantity | 2 |
| RS-232 interface | Yes |
| Design |
| Product design | Digital signage flat panel |
| Product colour | Black |
| Placement supported | Indoor |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Performance |
| Purpose | Universal |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
| Power |
| Power consumption (typical) | 363 W |
| Power consumption (standby) | 0.5 W |
| Input voltage | 100-240 V |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Computer system |
| Internal memory | 16 GB |
| Operating system installed | Tizen 7.0 |
| Weight & dimensions |
| Display width | 2193.2 mm |
| Display depth | 48.1 mm |
| Display height | 1248.8 mm |
| Display weight | 56.3 kg |
| Packaging data |
| Package width | 2370 mm |
| Package depth | 230 mm |
| Package height | 1395 mm |
| Package weight | 77.2 kg |
| Operational conditions |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Network |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Other features |
| Audio output | 1 |
| RS-232 input ports | 1 |
| RS-232 output ports | 1 |
| RJ-45 input ports | 1 |
