| Processor |
| Processor family | Intel® Core™ i5 |
| Processor manufacturer | Intel |
| Processor model | i5-10500T |
| Processor frequency | 2.3 GHz |
| Processor generation | 10th gen Intel® Core™ i5 |
| Processor cores | 6 |
| Processor threads | 12 |
| Processor boost frequency | 3.8 GHz |
| Processor cache | 12 MB |
| Processor cache type | L3 |
| Configurable TDP-down | 25 W |
| Configurable TDP-down frequency | 1.7 GHz |
| Memory |
| Internal memory | 16 GB |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 2666 MHz |
| Non-ECC | Yes |
| Storage |
| Total storage capacity | 256 GB |
| Optical drive type | No |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | PCI Express |
| NVMe | Yes |
| Graphics |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® HD Graphics 630 |
| Network |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ports & interfaces |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Thunderbolt 3 ports quantity | 0 |
| HDMI ports quantity | 0 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| Combo headphone/mic port | Yes |
| Design |
| Chassis type | Mini PC |
| Product colour | Black |
| Number of 2.5" bays | 1 |
| Performance |
| Product type | Mini PC |
| Market positioning | Proven productivity |
| Motherboard chipset | Intel Q470 |
| Password protection | Yes |
| Password protection type | BIOS, Power on, User |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software |
| Operating system installed | Windows 11 Pro |
| Pre-installed software | HP Noise Cancellation Software; HP Support Assistant; Buy Office (sold separately); HP JumpStarts; HP Desktop Support Utilities |
| Processor special features |
| Intel 64 | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | No |
| Intel Clear Video Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Idle States | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Brand-specific features |
| HP JumpStart | Yes |
| HP Support Assistant | Yes |
| HP Security tools | Power-on password (via BIOS); SATA port disablement (via BIOS); Setup password (via BIOS); Support for chassis padlocks and cable lock devices; USB enable/disable (via BIOS); Serial enable/disable (via BIOS); HP Secure Erase; HP Sure Click; HP Sure Sense; HP DriveLock and Automatic DriveLock; Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10. (Common Criteria EAL4+ Certified); HP Sure Recover Gen3; HP Sure Run Gen3; HP Sure Start Gen6; HP BIOsphere Gen6; HP Client Security Manager Gen6 |
| HP Management tools | HP BIOS Config Utility (download); HP Client Catalog (download); HP Driver Packs (download); HP System Software Manager (download); HP Cloud Recovery; HP Management Integration Kit for Microsoft System Center Configuration Management Gen 4; HP Image Assistant Gen 5 |
| HP segment | Business |
| Power |
| Power supply | 65 W |
| Operational conditions |
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Sustainability |
| Sustainability certificates | ENERGY STAR |
| Sustainable technologies and materials | Low halogen |
| Weight & dimensions |
| Width | 177 mm |
| Depth | 175 mm |
| Height | 34 mm |
| Weight | 1.25 kg |
| Packaging data |
| Package width | 498 mm |
| Package depth | 235 mm |
| Package height | 132 mm |
| Package weight | 3.4 kg |
| Logistics data |
| Harmonized System (HS) code | 8471500000 |
| Display |
| Display included | No |
| Audio |
| Audio chip | Realtek ALC3867 |
| Brand-specific features |
| HP GTIN (EAN/UPC) with options | (ABB) 197497555004; (ABD) 197497555028; (ABH) 197497555035; (ABU) 197497555011; (ABY) 197497555059; (UUW) 197497555042 |
| HP GTIN (EAN/UPC) | 197497555004, 197497555028, 197497555035, 197497555011, 197497555059, 197497555042 |
| Other features |
| Number of free internal memory expansion slots | 1 |
