| Processor |
| Processor family | Intel® Xeon® E5 Family |
| Processor manufacturer | Intel |
| Processor model | E5-2660 |
| Processor frequency | 2.2 GHz |
| Processor boost frequency | 3 GHz |
| Processor cores | 8 |
| Processor cache | 20 MB |
| Motherboard chipset | Intel® C602 |
| Memory channels supported by processor | Quad |
| Number of processors installed | 2 |
| Thermal Design Power (TDP) | 95 W |
| Processor cache type | Smart Cache |
| System bus rate | 8 GT/s |
| Maximum number of SMP processors | 2 |
| Compatible processor series | Intel® Xeon® |
| Processor socket | LGA 2011 (Socket R) |
| Processor lithography | 32 nm |
| Processor threads | 16 |
| Processor operating modes | 64-bit |
| Stepping | C2 |
| FSB Parity | No |
| Bus type | QPI |
| Number of QPI links | 2 |
| Processor codename | Sandy Bridge EP |
| Tcase | 73 °C |
| Maximum internal memory supported by processor | 750 GB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 800,1066,1333,1600 MHz |
| Memory bandwidth supported by processor (max) | 51.2 GB/s |
| ECC supported by processor | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Maximum number of PCI Express lanes | 40 |
| PCI Express configurations | x4, x8, x16 |
| Processor package size | 52.5 x 45.0 mm |
| Supported instruction sets | AVX |
| Scalability | 2S |
| Physical Address Extension (PAE) | 46 bit |
| Embedded options available | No |
| Graphics & IMC lithography | 32 nm |
| CPU multiplier (bus/core ratio) | 30 |
| Processor series | Intel Xeon E5-2600 |
| Conflict-Free processor | No |
| Intelligent Platform Management Interface (IPMI) support | Yes |
| Memory |
| Internal memory | 256 GB |
| Internal memory type | DDR3-SDRAM |
| Maximum internal memory | 768 GB |
| Maximum internal memory | 786432 MB |
| Memory slots | 24x DIMM |
| ECC | Yes |
| Memory clock speed | 1600 MHz |
| Memory layout (slots x size) | 1 x 8 GB |
| Storage |
| Maximum storage capacity | 32 TB |
| Total storage capacity | 6.3 TB |
| RAID support | Yes |
| Optical drive type | DVD-RW |
| Number of HDDs installed | 0 |
| Number of HDDs supported | 16 |
| Supported HDD sizes | 2.5" |
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
| Internal drive bays | 16 |
| Supported storage drive interfaces | Serial ATA |
| Network |
| LAN controller | Broadcom 5720 |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports | 4 |
| Expansion slots |
| PCI Express x8 slots | 6 |
| PCI Express x16 slots | 1 |
| PCI Express slots version | 3.0 |
| Design |
| Chassis type | Rack (2U) |
| Rack mounting | Yes |
| Redundant fans support | Yes |
| Performance |
| Remote administration | iDRAC Enterprise |
| Performance management | IPMI 2.0, Dell OpenManage |
| Trusted Platform Module (TPM) | Yes |
| Software |
| Compatible operating systems | Windows Server 2012\r\nWindows Server 2008 R2 SP1 (64-bit)\r\nWindows Small Business Server 2011\r\nNovell SUSE Linux Enterprise Server\r\nRed Hat Enterprise Linux\r\nCitrix XenServer\r\nVMware vSphere ESXi\r\nRed Hat Enterprise Virtualization |
| Processor special features |
| CPU configuration (max) | 2 |
| Intel Rapid Storage Technology | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Insider™ | No |
| Intel Flex Memory Access | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Demand Based Switching | Yes |
| Intel® Secure Key | Yes |
| Intel Clear Video Technology | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel 64 | Yes |
| Intel Identity Protection Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 0.00 |
| Intel Dual Display Capable Technology | No |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Processor ARK ID | 64584 |
| Power |
| Redundant power supply (RPS) support | Yes |
| Power supply | 750 W |
| Number of redundant power supplies installed | 2 |
| Number of main power supplies | 2 |
| Sustainability |
| Sustainability certificates | ENERGY STAR |
